Feature
Light weight,one person is able to carry one cabinet and install easiy.It makes the screen convenient in assmbly and transport.
Urtra Thin,the depth of the cabinet is less than 80mm.
Seanless assembly,the whole cabinet is die-cast.
State-of-art indoor 3in1 SMD.
Specification
Parameter Unit Value Pitch mm 1.48 Brightness nits 600 Color temperature deg. K 6,500 Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70) Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70) Panel weight kg 8 Panel width mm 640 Panel height mm 480 Panel depth mm 80 Panel area sq. m. 0.4096 Panel material Epoxy paint coated Aluminum Service access Front service Operating temperature range deg. C -20 to +60 Humidity operating RH 10% ~ 60% Pixel type and configuration R/G/B 3-in-1 SMD 2020 Resolution per panel 432*324 Dot per panel 139,968 Dot per sq. meter 455,625 LED per sq. meter 455,625 Recommended minimum viewing distance m 1.1 Recommended best viewing distance m 1.4~50m Colors 281 Trillion Grey scale (linear) Levels 65,536 Brightness control Levels 256 Contrast ratio 3,000:1 Processing depth bit 16 Video frame rate Hertz 60 Display refresh rate Hertz 3,840 Input voltage (nominal) VAC 110 to 240 Input power frequency Hertz 50 to 60 Input power (max) Watts / panel. 200 Input power (typical) Watts / panel. 80 Lifetime (50% brightness) Hours ≥100,000 Red wavelength (dominant) nm 620~625 Green wavelength (dominant) nm 520~525 Blue wavelength (dominant) nm 470~475 Multimedia data format DVI,MPG,AVI,WMV,RM etc. Data interconnection UTP Cat 5/Optical Fiber Mounting system Hanging/Fixed
