Specification
Application Indoor Pitch 1.56mm Pixel density 409600dot/sq.m LED density 409600dot/sq.m Brightness 600nit Color temperature 6500deg. K Viewing angle – Horizontal 140(-70 ~ +70) deg. Viewing angle – Vertical 140(-70 ~ +70)deg. Module size(W*H) 300*168.75mm Module resolution(W*H) 192*108pixel Module Qty(W*H) 2*2=4pcs Cabinet size(W*H) 600*337.5mm Cabinet depth 63mm Cabinet sq. meter 0.2025sq.m Cabinet resolution(W*H) 384*216pixel Cabinet material Die-cast aluminum Cabinet weight 8kg/cabinet Cabinet mode Fixed installation Service access Front service Ingress protection (front/rear) IP23 Operating temperature range -30 to +60 deg. C Humidity operating 10% ~ 90% RH Pixel type and configuration 3in1 SMD Recommended minimum viewing distance 1.4m Recommended best viewing distance 2~100m Colors 281 Trillion Grey scale (linear) 65536 levels per color Brightness control 100Levels Contrast ratio 4000:1 Processing depth 16bit Video frame rate 60Hertz Drive IC MBI5153 Display refresh rate 3840Hertz Input voltage (nominal) 110 or 220VAC Input power frequency 50 to 60 Hertz Input power (max) 200 Watts/ cabinet Input power (typical) 80 Watts/ cabinet Lifetime (50% brightness) ≥100000 Red wavelength (dominant) 620~625 Green wavelength (dominant) 525~530 Blue wavelength (dominant) 470~475 Multimedia data format DVI,MPG,AVI,WMV,RM etc. Data interconnection UTP Cat 5/Optical Fiber Mounting system Fixed with 4pcs M10 bolts Controller NOVA
